LJ10 Series Open-Hopper PC Pump for Fruits and Vegetables

LJ10 Series Open-Hopper PC Pump for Fruits and Vegetables

The LJ10 Series Open Hopper Progressive Cavity Pump is an ideal pumping solution for low-flowable mediums with high solids contents such as vegetables and fruits. Flow rates of 18.8 GPM/ per 100 Revolutions (52 GPM to 84 GPM) at 225 PSI are standard through the range of the series. The Justice Series offers a design of a heavy-duty auger conveyor screw mated to a rotor and stator for the most difficult pumping applications.

The large rectangular feed hopper design easily accommodates your pumping medium while the non-pulsating design of the product produces a low-shear flow that conveys your medium along effortlessly. Solids in suspension of up to 50% are accommodated by the Auger design.

The modular design of the LJ10 Series is a hardened pinned-joint drive assembly with a body available in steel or 316 stainless steel and internal wetted components in either stainless steel or hardened tool steel with hard chrome plating for long-life and durability in abrasive pumping applications.

Rotors and Stators for the LJ10 Series are available in 1, 2, and 3 stages for applications with 75, 150, and 225 PSI discharge pressures with stators available in Buna Nitrile, Viton®, EPDM and Natural Rubber. The standard seal design is a set of packing with a lantern ring and flush connections. Mechanical Seal options are readily available.

Technical Data

  • FLOW RATE – 52 – 84 GPM
  • PRESSURE – 0 – 225 PSI
  • SEAL OPTIONS – Packing & Mech Seal
  • BASE OPTIONS – Steel and Stainless Steel
  • INLET/OUTLET – 26″ x 12″ / 5″ NPTF
  • ROTORS – Tool Steel & Stainless Steel, Chrome-Plated
  • STATORS – Buna, Rubber, Viton®, EPDM
  • MOTOR OPTIONS – 5, 10, 15 HP

Features

  • Large Hopper
  • Welded Auger
  • Hardened Joints
  • Packing or Mechanical Seal
  • 3-Stage Options
  • Steel or Stainless Steel

Click here for LJ10 PC Pump Brochure
