S1F Sandpiper AODD Standard Duty Non-Metallic Pump

Standard Duty Metallic Pumps are ideally suited for intermittent / on-demand, portable, moderately abrasive fluids, and suspended solids. Standard duty pumps are constructed in Aluminum, Cast Iron, Stainless Steel and non-metallic materials such as PTFE, Polypropylene, and PVDF with elastomer TPE (thermal plastic elastomers) and PTFE options in diaphragms and check valves.

Specifications

Port Size
1″ ANSI Flange
PN10 25mm DIN Flange
Capacity
0 to 53 gpm (200 lpm)
Air Distribution Valve
No-lube, no-stall design
Solids-Handling
Up to .25″ (6 mm)
Heads Up To
100 psi or 231 ft. of water (7 bar or 70 meters)
Displacement/Stroke
.19 gallons (.72 liters)
Max Operating Pressure
100 psi (7 bar)
Shipping Weight
Polypropylene: 42 lbs. (19 kg)
PVDF: 54 lbs. (24 kg)

Click here for S1F Standard Duty Pump Data Sheet.
