FLUX F560 GS Gear Drive Pump
The FLUX F560 GS progressive cavity pump with planetary gear is suitable to pump thin to medium viscosity liquids. This positive displacement pump works smoothly at a constant pressure and ensures a gentle, pulsation-free pumping. The pump is especially designed to meet the specific requirements of the food, cosmetic and pharmaceutical industries. Models can be used in mobile and fixed installations. With only a few components used for assembly, the pump can be easily dismantled, cleaned and serviced.
- Available as 3A Certified and FDA compliant
- Positive displacement pump that offers smooth pumping and with very little shear
- Comprehensive modular system for ease of maintenance
- Wide range of viscosity can be covered
- Transfer rate is maintained at constant pressure
- High efficiency pumping
- Available with ATEX certification for use in hazardous area
- Can be used in horizontal applications
Technical Data
- Flow Rate: max 12 GPM (45 l/min)
- Delivery Pressure: max 116 PSIG
- Viscosity: 1 – 50,000 cPs
- Outer Tube Diameter: 1.97 in – 2.13 in (50 – 54 mm)
- Standard Immersion Lengths: 27, 39, 47, 60 in (700, 1000, 1200, 1500 mm)
- Materials of Construction: Stainless Steel
- Temperatures to 248°F (120°C)
- Seal: mechanically sealed
- Containers: 55 Gal Drums, totes, IBCs
