Private: Sine Pump Sanitary Positive Displacement Pumps

Sine’s MR pump satisfies demanding processing requirements cost-effectively, using the unique Sine pumping principle.

Design Advantages

  • Powerful suction even for viscous products
  • Low pulsation for smooth, consistent flow
  • Low-shear action does not damage fragile and shear-sensitive fluids
  • Wearing parts easily replaced on site
  • Holds 3-A Sanitary Standards authorization

Typical Applications

  • Cheese, curds and whey, cottage cheese, butter, yogurt
  • Fruit concentrates, syrups, beer, wort, yeast
  • Batter, frosting, fillings, slurries
  • Soups, stews, deli salads
  • Chocolate, caramel, fruit fillings

Features

  • Exclusive sinusoidial rotor
  • Vacuum lifts to 9m (30 feet) of water (28” Hg)
  • Single rotor design
  • Large pumping chambers for fragile particulates
  • Simple design
  • 3A Certified

Benefits

Gentle, low shear product handling
Safely pumps highly viscous products
Very low pulsation
Preserves and maintains product integrity
Economical in-line maintenance and cleaning
Reliable, safe service

Specifications

Flows To99m³/hr (434gpm)
Max Working Pressure10kg/cm² (145psi)
Temp range -40 to 100°C (40 to 212°F)
Standard DeliveryFor standard pump incl drive 1 to 2 weeks, Standard pump bare shaft without drive 1-2 days
Speed Range600 rpm max
Materials of Construction316 Stainless Steel, Polyamide
Max Viscosity2,000,000 centistokes
Typical ApplicationsCheese, curd, deli salads, soup, chicken muscle, ground beef, juice concentrates, chocolate, dough, lotions, shampoos, lipstick, polymers, paints
IndustriesDairy, prepared foods, meat & poultry, beverage, confection, bakery, seafood, pharmaceutical, cosmetic, industrial
Industry StandardSanitary 3A, USDA Meat & Poultry
Solids Rangeup to 2.5″ (65mm) diameter
Sizes Available6
Seal Configurations AvailableLip Seal, O-ring, Single Mechanical, Double Mechanical
Available FlangesTri-Clamp, Bevel Seat, DIN, SMS, ANSI 150# RF
Suction and Discharge Size 50mm x 50mm (2″ X 2″),  63mm x 63mm (2.5″ X 2.5″),  76mm x 76mm (3″ X 3″),  100mm x 100mm (4″ X 4″),  150mm x 150mm (6″ X 6″)
Displacement per Revolution 0.13 – 2.75 Liters (0.03 – 0.72 GAL)
